Zebra DS8108 Corded Barcode Scanner
Short Description
The Ultimate in Performance, Innovation and Manageability
The DS8108 rises above conventional imagers, providing unprecedented scanning performance so cashiers and self-checkout customers can easily scan any barcode the first time, every time. You get a wide range of innovations, including interchangeable power sources — a PowerPrecision+ battery and PowerCapTM capacitor. And every DS8108 imager is engineered with DataCapture DNA, Zebra exclusive software ecosystem that simplifies every stage of the scanning experience over the life of your device. Keep checkout lines moving with the DS8100 Series, the ultimate in handheld scanning performance and innovation.
Authorized Distributor of Zebra DS8108 Handheld Barcode Scanner
Physical Characteristics
| Dimensions | 6.6 in. H x 2.6 in. W x 4.2 in. D 16.8 cm. H x 6.6 cm. W x 10.7 cm. D |
| weight | 5.4 oz./154 g |
| Input Voltage Range | 4.5 to 5.5VDC |
| Supported Host Interfaces | USB Certified, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485 |
| User Indicators | Direct decode indicator, good decode LEDs, rear view LEDs, beeper |
Performance Characteristics
| Light Source | Aiming Pattern; circular 617nm amber LED |
| Illumination | (2) 645nm red LEDs |
| Image Sensor | 1,280 x 960 pixels |
| Minimum Print Contrast | 16% minimum reflective difference |
| Skew/Pitch Roll Tolerance | +/- 60°; +/- 60°; 0-360° |
User Environment
| Operating Temperature | 32° to 122° F/0° to 50° C |
| Charging Temperature | 32° to 104° F/0° to 40° C |
| Storage Temperature | -40° to 158° F/-40° to 70° C |
| Humidity | 5% to 95% RH, non-condensing |
| Drop Specification | Designed to withstand multiple drops at 6.0 ft/1.8 m to concrete |
| Tumble Specification | Designed to withstand 2,000 1.5 ft./0.5 m tumbles3 |
| Environmental Sealing | IP52 |
Put the Zebra DS8108 Handheld Barcode Scanner to Work in
Retail
- Point-of-Sale (POS)
- Self-checkout
- Buy Online Pickup In Store
- Buy Online Pickup At Curb
- Loyalty applications
- Electronic coupon redemption
- Backroom receiving
- Inventory management
Hospitality
- Check-in
- Ticketing
- Loyalty cards
Transportation
- Shipping and receiving
- Picking
- Product tracking
- Ticketing
- Postal
Light/Clean Manufacturing
Government
- Lottery and gaming
- Administration
- Banking
